Level Control: Sensors
Our sensors work without direct contact to the liquid - for maximum safety and cleanliness. Simply attach the sensor to the container at the desired height.
Do you have questions or need an individual solution? Give us a call or use our contact form!
Use our new configurator to narrow down your selection:
Configurator
Capacitive disc sensor, Ex
Product no.: 108291
Capacitive disc sensor
- housing material: stainless steel
- Active surface: PTFE
- length cable = 2 m
- for ATEX zone 0, ATEX Ex II 1G Ex ia IIC T1-T6 Ga, output function: NAMUR
- operating distance 1 - 10 mm adjustable
- Switch amplifier necessary (108278)
Capacitive leakage sensor, Ex
Product no.: 108301
Capacitive sensor for leakage control
- housing material: PTFE
- for ATEX zone 1, ATEX Ex II 2G EEx ia IIC T1-T4, output function: NAMUR
- operating distance 0.5 - 3 mm adjustable
- Switch amplifier necessary (108278)
Capacitive rod sensor, M12, 2m
Product no.: 108277
Capacitive rod sensor
- housing material: PTFE
- thread: M12x1
- length sensor = 70 mm
- with LED display
- length cable: 2 m
- for ATEX zone 0, ATEX Ex II 1G Ex ia IIC T1-T6 Ga, output function: NAMUR
- operating distance 1 - 6 mm adjustable
- Switch amplifier necessary (108278)
Capacitive rod sensor, M12, 5m
Product no.: 108303
Capacitive rod sensor
- housing material: PTFE
- thread: M12x1
- length sensor = 70 mm
- with LED display
- length cable: 5 m
- for ATEX zone 0, ATEX Ex II 1G Ex ia IIC T1-T6 Ga, output function: NAMUR
- operating distance 1 - 6 mm adjustable
- Switch amplifier necessary (108278)
HPLC disposal set + level control
Product no.: 307323
HPLC disposal set + level control
- Canister, 10 liter, S60/61, PE-HD electrostatic conductive with integrated welded sensor holder with sensor for level control
- Capacitive rod sensor for the level measurement made of brass, with ATEX-license, II 2 G EEx ia IIC T1-T6, NAMUR
HPLC supply set + alarm when empty
Product no.: 307322
HPLC supply set + alarm when empty
- Canister, 10 liter, S60/61, PE-HD electrostatic conductive with integrated welded sensor holder with sensor for empty state
- Capacitive rod sensor for the level measurement made of brass, with ATEX-license, II 2 G EEx ia IIC T1-T6, NAMUR
